Singlemode SC/APC Field Installable Connector

Brand Name : QY

Model Number : QSC52ZJ2-APC

Certification : ISO, CE, ROHS

Place of Origin : Dongguan, China

MOQ : 100pcs for minium order

Price : Negotiable

Payment Terms : L/C, T/T, Western Union,Paypal

Supply Ability : 10,000pcs per day

Delivery Time : 5-8 working days

Packaging Details : Blister package or PE bag or customized package & cartons

Connector Type : SC

Polishing : APC

Ferrule : Ceramic

Fiber Mode : 9/125μm Singlemode

Cable Diameters : 2.0/3.0mm

Insertion Loss : ≤0.35dB

Return Loss : ≥45dB

Tension Test : 30N

Temperature : -40 to 75°C

Product ID : 000018

Contact Now

Overview

High-quality SC field-installable connectors (FIC), factory terminated and polished to make fiber fast and reliable terminations. The use of the FIC SC connector reduces the installation time providing ease of use with reliable results. These connectors have a window feature so that they can be tested with a visual fault locator. They require no polishing, crimping or epoxy.

Singlemode SC/APC Field Installable Connector

Features

• Factory price, can be reused
• Using simple tools without electrical power, no special tools are needed to install
• Easy and fast installation, 30 seconds to learn to install, 90 seconds to operate in the field
• No need for polishing or adhesive, ceramic ferrule with embedded fiber stub is pre-polished
• Fiber aligned in v-groove through the ceramic ferrule
• Low-volatile reliable matching liquid preserved by side cover
• Unique bell-shaped boot maintains the minimum fiber bend radius

Application

FTTH
For the connection between the distribution box and RRH
Deployment in Remote Radio Head cell tower applications
Backbone installation
Data center cabling
Telecommunication network
Industrial & Military

Singlemode SC/APC Field Installable Connector
